Protekt 600 Electric Full-Body Lift, 600 lb
Protekt 600 Electric Full-Body Lift — 600 lb, Wide Base, Floor-Capable
Overview
The Protekt 600 is the highest-capacity full-body lift in the Protekt line — a full-electric, battery-powered system that makes safe, controlled transfers possible at higher weights. A hand pendant raises and lowers the boom with no pumping, and a wide base that opens to 45 inches gives maximum stability at full capacity. With a 600 lb rating, it operates comfortably within its design limits where it counts, and a six-point clip-free spreader bar with 360-degree rotation accepts 2-, 4-, or 6-point slings for a full range of transfers between bed, chair, wheelchair, and commode.
It's built on the same proven platform as the Protekt 500, so everything that lift does well carries over: a low, floor-capable base (22.8-inch minimum lifting height) that slides under most beds, an ergonomic foot pedal that opens and locks the base hands-free, manual emergency lowering and an emergency stop for safety, and a 24-volt battery good for 20-plus lifts per charge. A modular design keeps maintenance and parts replacement simple, an optional digital scale is available, and the lift is backed by a 3-year frame, 2-year electronics, and 1-year battery warranty. A sling is selected separately.
Key Features
- Full-electric, battery-powered — a hand pendant raises and lowers the boom, no pumping.
- 600 lb weight capacity — the highest in the Protekt line.
- Wide base opens to 45″ for maximum stability at full capacity.
- Six-point clip-free spreader bar — 2-, 4-, or 6-point slings, 360° rotation.
- Floor-capable (22.8″ minimum lifting height); low base fits under most beds.
- Hands-free foot pedal opens and locks the base.
- Manual emergency lowering and emergency stop.
- Dual rear locking casters (4″ rear with brakes, 3″ front).
- 24V battery — 20+ lifts per charge; auxiliary up/down controls.
- Modular design for easy parts replacement.
- Optional digital scale.
- Warranty: frame 3-year, electronics 2-year, battery 1-year.
Equipment Specialist Insight: The 600 is the highest-capacity lift in the Protekt line, and the meaningful upgrade over the 500 is that wider base — it opens to 45 inches for extra stability at higher weights — plus the full 600 lb rating, so you're working within the design limits rather than at the edge of them. Everything else carries over from the 500: the battery boom (no pumping), the clip-free six-point spreader bar, the hands-free foot pedal, and the floor-capable low base. Slings are chosen separately and rated by capacity, so for higher weights confirm the sling is rated to match. A rule of thumb: if the weight is comfortably under 500 lbs, the 500 has a narrower base that fits through tighter spaces; step up to the 600 when you want the capacity margin and the added stability. It ships by ground carrier, with warranty coverage of 3 years on the frame, 2 on electronics, and 1 on the battery.
Technical Specifications
- BrandProtekt (Proactive Medical)
- ModelProtekt 600 Lift (33600)
- TypeElectric full-body floor lift (high capacity)
- Weight Capacity600 lbs
- Power24V rechargeable battery (20+ lifts/charge)
- ControlsHand pendant + auxiliary up/down
- Spreader BarSix-point, clip-free, 360° rotation (2/4/6-point slings)
- Floor LiftYes (22.8″ min lifting height)
- Base Width (open)45″
- Base AdjustmentHands-free foot pedal (locks)
- Casters4″ locking rear, 3″ front
- SafetyManual emergency lowering, emergency stop
- DesignModular (easy parts replacement)
- OptionsDigital scale; sling (sold separately)
- WarrantyFrame 3-yr, electronics 2-yr, battery 1-yr
- Sold AsEach
Is a sling included?
Slings are selected separately so you can match the style to the need — and for higher weights, confirm the sling's rating matches. The six-point clip-free spreader bar fits 2-, 4-, or 6-point slings.
How is the 600 different from the Protekt 500?
They share the same platform. The 600 adds capacity (600 lb) and a wider 45″ base for extra stability. The 500 has a narrower base that fits through tighter spaces — choose it if the weight is comfortably under 500 lbs.
Can it lift from the floor?
Yes. It's floor-capable, with a 22.8″ minimum lifting height, and the low base slides under most beds.
A sling is sold separately. Retail packaging and specifications may be updated by the manufacturer without notice. This is a heavy item; confirm proper sling selection, fit, and weight rating before lifting, ensure caregivers are trained on safe operation, and always follow the manufacturer's instructions.
