Span America Geo-Mattress 350 Segmented Foam Mattress
Model: Geo-Mattress 350 (67535-29 / 68035-29 / 68435-29)
Availability: In Stock – Ready to Ship
A 6-Inch Segmented Foam Care Mattress With a Heel Slope and 350 lb Capacity
The Span America Geo-Mattress 350 is a non-powered foam mattress for home care and long-term care beds. It is made from a single 6-inch layer of combustion-modified foam with a cross-cut, segmented top surface; the individual cells flex independently and conform to the body, which helps redistribute pressure across the surface. At the foot end, a tapered heel slope is designed to shift load away from the heels and onto the lower legs. It supports users up to 350 lbs.
The cover is fluid-proof, bacteriostatic, fire-resistant and tear-resistant, wipes clean, and can be replaced on its own. Its pleated design is fully integrated with the mattress to reduce hammocking, so the foam surface can conform as intended. The mattress weighs about 21 lbs and ships folded and boxed. It comes in three lengths — 75, 80 and 84 inches — all 35 inches wide,.
Key Features
- Single 6″ layer of combustion-modified foam
- Cross-cut segmented top — conforms to the body to help redistribute pressure
- Heel slope — tapered foot end shifts load from the heels to the lower legs
- 350 lb weight capacity
- Fluid-proof, bacteriostatic cover — fire- and tear-resistant, wipe-clean, replaceable
- Pleated, integrated cover design — reduces hammocking
- Three lengths — 75″, 80″ or 84″; all 35″ wide
- Non-powered — no pump or electrical connection
- Flammability conformance — NFPA 101, Cal TB 117, 16 CFR 1632 and 1633
- 5-year limited warranty
Equipment Specialist Insight: Match the mattress length to the bed deck: measure the deck length before ordering, and choose 84″ for extended-length frames. A 6″ mattress may change how high bed rails sit above the sleep surface, so check rail height with the bed manufacturer’s guidance. Keep the heel slope at the foot of the bed. Clean the cover with a facility-approved disinfectant, and inspect it regularly for tears; the cover can be replaced without replacing the foam. If the user’s weight is near 350 lbs or they need more support, ask about higher-capacity Geo-Mattress models.
Technical Specifications
| Brand | Span America |
| Model | Geo-Mattress 350 |
| 67535-29 | 75″ L × 35″ W × 6″ H |
| 68035-29 | 80″ L × 35″ W × 6″ H |
| 68435-29 | 84″ L × 35″ W × 6″ H |
| Weight Capacity | 350 lbs |
| Mattress Weight | About 21 lbs |
| Construction | Single layer of combustion-modified foam; cross-cut segmented top; heel slope |
| Cover | Fluid-proof, bacteriostatic, fire-resistant, tear-resistant, cleanable, replaceable; pleated integrated design |
| Power | Non-powered |
| Flammability | NFPA 101 (ASTM E1590); Cal TB 117; 16 CFR 1632 and 1633 |
| HCPCS | E0184 |
| Warranty | 5 years, limited (includes a prorated period) |
| Shipping Format | Folded and boxed |
Frequently Asked Questions
Which length do I need?
Measure the bed deck. The mattress comes in 75″, 80″ and 84″ lengths, all 35″ wide and 6″ high.
What is the heel slope for?
The foot end of the mattress tapers down, which is designed to move load off the heels and onto the lower legs. Keep that end at the foot of the bed.
Does it need power?
No. It is a non-powered foam mattress, with no pump or electrical connection.
How do I clean it?
Wipe the fluid-proof cover with a facility-approved disinfectant. The cover is replaceable if it becomes damaged.
Specifications are compiled from manufacturer and vendor documentation and are subject to change without notice. Verify current details before purchase. Information on this page is for general reference only and is not a substitute for professional medical advice. Consult a healthcare provider about support surface selection, and follow the bed and mattress manufacturers’ instructions, including bed rail guidance.
